Specialized- Status Alloy 160 Base- Mullet Complete Mountain Bike

Specialized rounded out the Status 160’s fun-first frame with everything you need to keep the party going—big brakes, an X-Fusion Manic dropper post and Fox’s FLOAT 36 Rhythm Fork paired with a FLOAT X Performance shock, all brought together by the active, planted feel of our FSR suspension platform.

Fox’s FLOAT 36 Rhythm calls their venerable Grip damper into service in the name of adventurous riders everywhere, offering impressively controlled travel with plenty of trail-feel that puts confidence on speed dial. The two-position Sweep adjustment ensures the FLOAT 36 Rhythm is right at home dealing out its 160-millimeters of travel in just about any environment while 36-millimeter stanchions promise plenty of stiffness for precise handling at the limit.

Quality suspension unlocks some serious free speed, so to slow it all down, we tasked SRAM’s proven Code R brakes with stopping duties. Forged four-piston calipers offer serious stopping power, while 200-millimeter rotors on both ends of the bike promise plenty of fade-free bite when it matters.
Status 160 and the Stumpjumper have the SAME size chart.

SpecificationsFrameset

Seat Binder: Alloy, 38.6mm

Frame: M5 alloy chassis and rear-end, Mixed wheel Trail Geometry, threaded BB,12x148mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 160mm of travel

Suspension

Fork: FOX FLOAT 36 Rhythm, GRIP damper, two position Sweep adjustment, 15x110mm QR axle, 44mm offset, 160mm of travel

Rear Shock: FOX FLOAT X Performance, Rx Trail Tune, EVOL Air sleeve, 2-position lever w/ LSR adjustment, 230x60mm

Cockpit

Stem: Alloy Trail Stem, 35mm bar bore

Saddle: Body Geometry Bridge Comp, hollow Cr-Mo rails, 143mm

Grips: Deity, Knuckleduster, Black

Handlebars: Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 30mm rise, 780mm width

SeatPost: X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SLR LE lever, 34.9mm, S2: 125mm, S3/S4: 150mm, S5: 170mm

Brakes

Rear Brake: SRAM Code R, 4-piston caliper, hydraulic disc, 200mm

Front Brake: SRAM Code R, 4-piston caliper, hydraulic disc, 220mm

Drivetrain

Chainrings: 48/35T

Bottom Bracket: SRAM DUB, BSA 73mm, threaded

Cassette: SRAM NX Eagle PG-1230, 12-speed, 11-50t

Chain: SRAM NX Eagle, 12-speed

Rear Derailleur: SRAM NX Eagle, 12-speed

Crankset: SRAM NX Eagle, DUB, 170mm

Shift Levers: SRAM NX Eagle, trigger, 12-speed

Wheels

Rear Hub: Alloy, sealed cartridge bearings, 12x148mm thru-axle, 32h

Front Hub: Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h

Front Tire: Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3"

Rear Tire: Butcher, GRID TRAIL casing, GRIPTON® compound, 27.5x2.3"

Spokes: DT Swiss Industry

Rims: Specialized 29, hookless alloy, 30mm inner width, tubeless ready

Inner Tubes: Standard, Presta Valve

Geometry

	S1	S2	S3	S4	S5
Crank Length	170mm	170mm	170mm	170mm	170mm
Handlebar Width	800mm	800mm	800mm	800mm	800mm
Stem Length	40mm	40mm	40mm	40mm	40mm
Saddle Width	143mm	143mm	143mm	143mm	143mm
Seatpost Length	125mm	150mm	170mm	170mm	170mm
Stack (low BB)	610mm	614mm	623mm	632mm	641mm
Reach (low BB)	417mm	437mm	462mm	487mm	512mm
Head-Tube Length	95mm	100mm	110mm	120mm	130mm
Head-Tube Angle (low BB)	63.2°	63.2°	63.2°	63.2°	63.2°
Head-Tube Angle	63.7°	63.7°	63.7°	63.7°	63.7°
B-B Height (low BB)	338mm	338mm	338mm	338mm	338mm
B-B Height	347mm	347mm	347mm	347mm	347mm
B-B Drop (low BB)	17.5mm	17.5mm	17.5mm	17.5mm	17.5mm
B-B Drop	8.5mm	8.5mm	8.5mm	8.5mm	8.5mm
Trail (low BB)	141mm	141mm	141mm	141mm	141mm
Fork Length (full)	567mm	567mm	567mm	567mm	567mm
Fork Rake/Offset	44mm	44mm	44mm	44mm	44mm
Front-Center (low BB)	756mm	778mm	808mm	837mm	867mm
Chain-Stay Length	426mm	426mm	426mm	426mm	426mm
Wheelbase	1181mm	1203mm	1233mm	1264mm	1292mm
Seat-Tube Length	400mm	400mm	420mm	440mm	465mm
Seat-Tube Angle	76°	76°	76°	76°	76°
